Bently Nevada 3500/33 16-Channel Relay Module 3500/33-01

General info:

Part number:3500/33 3500/33-01

Manufacturer:Bently Nevada

Product Description:16-Channel Relay Module

The 3500/33-01-01 module, which is a 16-channel relay module that provides 16 relay outputs. The 3500 system is a rack-based machinery protection and condition monitoring system that continuously measures and monitors various protection and supervisory parameters .

Key Phase Generator Module 3500/25; Relay Module 3500/32M or 3500/33M; Communication Gateway Module 3500/92

Turbine vibration monitoring and protection system Bentley 3500TSI commonly used models are as follows.

TSI frame:3500/05-01-01-00-00-01 or 3500/05-02-04-00-00-01

TSI power supply: 3500/15-05-05-00 (replaces 3500/15-02-02-00)

Frame interface module: 3500/22-01-01-00

Frame configuration software: 3500/01-01

TSI displacement module: 3500/40-01-00

TSI vibration module: 3500/42-01-00

TSI Differential Expansion Module: 3500/45-01-00

TSI speed monitoring module: 3500/50-01-00-01

TSI Overspeed Monitoring Protection Module: 3500/53-03-00

TSI Key Phasor Module 3500/25-01-01-00

TSI relay module 3500/32-01-00.

TSI Relay 16-channel module 3500/33-01-00.

TSI Communication Gateway 3500/92-02-01-00

TSI Communication Gateway Module 3500/92-04-01-00

The Bentley 3500/42M provides independent 4 to 20 mA scaling values for each channel. The 3500/40M does not provide a 4 to 20 mA output

Features: 1. digital and analog communications; 2. highly flexible display options; 3. software configurable; 4. higher integration/fault tolerance; 5. alarm/event list; 6. API 670 standard; 7. all modules and power supplies (when using redundant power supplies) can be plugged in and out of the frame under powered conditions; 8. advanced data types

The 3500 system is used for continuous monitoring of rotating and reciprocating machinery in a wide variety of industries, and is particularly well suited for automatic shutdown machinery protection applications requiring extremely high reliability and availability. The types of machines to which the Bentley 3500 system can be applied include, but are not limited toGas turbines, steam turbines, compressors, turbo expanders, electric motors and generators, exciters, gearboxes, pumps, fans, fans, reciprocating compressors, extruders and pellet makers.

The available Bently (bently3500 series) monitor module channel types are as follows.

Radial vibration, axial (lateral) displacement, differential expansion, velocity, acceleration, shell expansion, valve position, standard tachometer, overspeed tachometer, shaft vibration, standard single slope differential expansion, double slope differential expansion, zero speed tachometer, etc.
