A-B  Y-3023-2-H00AA Brushless Servo Motor

Part number:  Y-3023-2-H00AA

Manufacturer:A-B

Product Description:Brushless Servo Motor

the A-B Allen-Bradley Y-3023-2-H00AA. This brushless servo motor is designed for use in industrial machines that require precise positioning, speed applications, and acceleration control. It is the largest frame size in the light industrial Y series and has an IP43 rated enclosure protection. The motor has a 3023 frame size, operates with a 230V ac Motor Winding Ke Designator, and has 8 poles. The Y-3023-2-H00AA has a maximum radial (FR) load of 35 kg and a speed rating of 4500 RPM. The motor has an optical encoder line count, but the break option is not included. The motor's high energy magnets (neodymium) provide low inertias for fast speeding up.

To use the Y-3023-2-H00AA servo motor, A-B recommends using the following servo drives: 1398-DDM-019, 1398-DDM202093-AM02, 2094-AM02, or 2098-DSD-020. The servo motor should be connected to the system with a rigid connection to prevent coupling, pulley, or belt slip over time. The connection cable should be as short as possible. The Y-3023-2-H00AA servo motor should be used in a standard industrial environment and should not be exposed to high humidity or high ambient temperatures. The motor's operating temperature range is 0 to 40 degrees Celsius (32 to 104 degrees Fahrenheit).

About Y-3023-2-H00AA

The Y-3023-2-H00AA is a brushless servo motor from Allen-Bradley’s Y series. Generally, its purpose is to perform sophisticated positioning and perfect speed applications, and acceleration control on industrial machines. It is a servo motor with largest frame size in the light industrial Y series. Its windings work with a 230 Volt AC voltage. Optical encoder line count is available and break option is not included. The Y-3023-2-H00AA servo motor high energy magnets (neodymium) provide low inertias for fast speeding up. Its speed rating is 4500 RPM. IP43 rated enclosure protection is obtained. The Y-3023-2-H00AA has 8 poles.

One of the features of the Y-3023-2-H00AA is a motor-mounted optical encoder line count with a 2000 P/R resolution and commutation signal. 5 Volt DC voltage is used for an encoder supply. A servo drive will be required to complete the servo drive positioning system. Allen-Bradley recommends the following servo drives to be used with any of the following servo motors: 1398-DDM-019, 1398-DDM-020, 2093-AM02, 2094-AM02, or 2098-DSD-020. The system connection with the servo motor shaft should be rigid in order to prevent couplings, pulleys, or belts from slipping over time and causing shaft deterioration. Connection cables should be made as short as possible. This module’s shipping weight is 3.9 kilograms (8.7 pounds). Its operating temperature range is 0 to 40 degrees Celsius (32 to 104 degrees Fahrenheit). The Y-3023-2-H00AA servo motor should be used in a standard industrial surrounding. Do not expose them to high-level moisture or high ambient temperatures. The Y-3023-2-H00AA dimensions are 140 x 80 x 80 millimeters (5.57 x 3.15 x 3.15 inches.). Its shaft diameter is 16 millimeters (0.63 inches).
