Product Overview
The 1336-BDB-SP23A printed circuit board or PCB is a gate driver PCB for Allen-Bradley Bulletin 1336 series adjustable frequency drives. the gate driver PCB is compatible with 1336 Plus (S), Plus II (F), Force (T), and Impact (E) drive models. the 1336-BDB-SP23A gate driver PCB operates at rated voltages of 575 volts AC, rated output power of 50 horsepower, and frequencies of 50 to 60 hertz. The gate driver PCB operates at a rated voltage of 575 volts AC, a rated output power of 50 horsepower, and a frequency of 50 to 60 Hz. 1336-BDB-SP23A The gate driver PCB supplies power to the main control and isolation boards by turning the IGBT braking circuitry on and off. The PCB is mounted between the main control board and the chassis with the gate driver mounting plate separating them. This board is designed to be a rugged, reliable industrial control component for speed and torque control of motors used in a wide range of industrial automation applications. It is an indispensable module in AC drives for a wide range of motor control applications, providing precise speed regulation and efficient control performance.
ALLEN BRADLEY 1336-QOUT-SP23A printed circuit board Specification:
Brand: Allen-Bradley
Product Family: Adjustable Frequency Drives
Bulletin Number: 1336
Product Type: Spare part
Assembly Level: Level 1; Major Assembly
Description: Gate Driver PCB
Compatible Drives: Plus (S), Plus II (F), Impact (E) and Force (T)
Voltage: 575V AC
Frequency: 50 - 60 Hz
Power Rating: 50 HP
Temperature Range: 0-60 degrees Celsius
