ABB SC510 3BSE003832R1 Communication Module.The SC510 3BSE003832R1 is a communication module and also a sub-module carrier without a CPU. It is applied in industrial communication and automation systems. The following are its main functions:
System Architecture Building
Sub-module Carrying: As a sub-module carrier, it provides physical installation support and electrical connection interfaces for other sub-modules, facilitating the construction of a modular control system. Communication, I/O and other sub - modules can be inserted as needed to flexibly configure the system functions.
System Expansion: It facilitates the expansion of the Advant Controller 450 system. By adding sub - modules, the communication, control, monitoring and other functions of the system can be easily expanded to meet the needs of industrial production scale expansion or process changes.
Communication Connection
Internal Communication: It is responsible for establishing the communication link between various modules within the Advant Controller 450 system, ensuring the smooth transmission of data and instructions between CPU modules, I/O modules, etc.
External Communication: It supports multiple communication protocols and can be connected to external devices such as sensors, actuators, other controllers and host computers. It enables data collection from field devices, output of control signals, and information interaction with the upper-level monitoring system.
Data Processing and Transmission
Data Transmission: In accordance with the communication protocol, it reliably transmits process variables (such as temperature, pressure, etc.), device status, control parameters and other data, ensuring the accuracy and timeliness of data to avoid affecting the system control performance.
Data Pre-processing: It performs pre-processing such as data format conversion and verification on the transmitted data. It converts data in different formats into a standard format recognizable by the system and ensures the reliability of data through verification.(Products that are used in conjunction with the SC510 3BSE003832R1 in the Advant Controller 450:PM511V16 3BSE011181R1 Processor Module,SR511 3BSE000863R1 Regulator,SC520 3BSE003816R1 Sub-module Carrier,SC513AK01 3BSE091971R1 Communication Interface Module)
Data sheet:
Advant Controller 450 Product Guide.pdf
SC510 3BSE003832R1 Communication Module Functional Features:
Powerful processing capability: It has high-performance processing capabilities, enabling real-time control and monitoring of industrial processes. It can meet the requirements of high-end and complex-function application scenarios.
Rich communication protocol support: It supports multiple communication protocols such as Modbus, Profibus, Masterbus 300/300E, and Advant Fieldbus 100, facilitating the construction of an optimal control system architecture.
Flexible hardware configuration: It adopts a modular design based on the industry-standard Future Bus+(IEEE 896). There are hardware options such as redundant CPU boards, sub-module carriers, and communication sub-modules, allowing for flexible configuration. For example, the CPU sub-rack has two positions for redundant CPU modules, and the sub-module carrier can be equipped with communication sub-modules.
High-availability guarantee: It can be equipped with redundant communication, power supply, CPU, and I/O boards. In the redundant processor module, when the main processor runs the control application, the backup processor is in hot-standby mode and is automatically updated. In case of a fault, it can automatically switch without disturbance within 5 - 10 ms.
Extensive I/O support: It supports the S800 I/O system (including field devices that support HART data) and the S100 I/O rack. The S100 I/O rack can be distributed through a redundant fiber - optic network, with a maximum I/O capacity of up to 5,700 I/O points.
Multiple control functions: It covers functions such as regulatory control (including advanced PID and self-tuning adaptive control), logic and sequential control, data and text processing, arithmetic operations, and positioning. It supports online configuration, and hardware can be added during operation.
size:290*25*486mm
Weight:1 kg
SC510 3BSE003832R1 Communication Module Application Areas:
It is suitable for industrial fields such as chemical, power, and manufacturing, which have high requirements for the reliability and performance of control systems. It can help enterprises ensure efficient production while controlling project costs.
