The Eaton XV-152-D6-84TVRC-10 is an 8.4-inch TFT resistive touch panel display module,Human-computer interaction in industrial automation control systems for equipment monitoring, parameter setting, data visualization and real-time control.
Technical Parameter
Brand/Model: EATON XV-152-D6-84TVRC-10
Type: Industrial Human Machine Interface (HMI)
Screen: 8.4-inch TFT LCD, resistive touch screen (supports single-touch)
Usage: HMI in industrial automation control system for equipment monitoring, parameter setting, data visualisation and real-time control.
Specifications and Technical Parameters
Display Performance
Resolution: 800 x 600 pixels (SVGA)
Brightness: 250 cd/m² (typical)
Contrast ratio: 500:1
Backlight life: 50,000 hours (LED backlight)
Touch Screen Characteristics
Type: Resistive (4-wire or 5-wire, subject to confirmation)
Operation method: Finger or stylus
Durability: 1,000,000 touch operations
Hardware Configuration.
Processor: High-performance ARM Cortex-A series (specific model to be confirmed)
Memory: 128MB RAM + 256MB Flash (or higher, depending on firmware version)
Storage Expansion: SD card/USB support (depending on model features)
Communication interfaces
Industrial protocols: Modbus RTU/TCP, EtherNet/IP, Profinet, CANopen (compatibility to be checked)
Ports: 1 x Ethernet 10/100Mbps, 10/100Mbps, 10/100Mbps
1× Ethernet 10/100Mbps
2× RS-232/RS-485 (serial port)
1× USB 2.0 (host/device)
Power Supply and Environment
Input Voltage: 24V DC (±20%)
Power Consumption: Approx. 10W (typical)
Operating temperature: -20°C to +60°C
Protection rating: IP65 (front panel)
Approvals and Standards
CE, UL, RoHS, FCC
Compliant with industrial EMC immunity standards (IEC 61000-6-2/6-4)
To learn more about this product click on the file below or download the file:
EATON XV-152-D6-84TVRC-10 Features:
Software Support.
Compatible with Eaton HMI programming software (e.g. EasyBuilder Pro or customised platforms)
Multi-language interface switching (Chinese, English, etc.)
Data logging and trend graph display
Alarm management and history log
Security Features.
Hierarchical management of user rights (password protection)
Operation log audit
Expandability.
Supports seamless integration with PLC, inverter, sensors and other equipment.
Optional wireless module (need to confirm the model support)
