ABB PM802F 3BDH000002R1 Base Unit controller AC 800F.The PM802F 3BDH000002R1 Base Unit Controller is one of the core components in the ABB AC 800F series of control systems. It is a high-performance base control unit designed for medium to large automation systems for industrial process control, manufacturing automation, energy management, and other control applications requiring high reliability and flexibility.
The PM802F Base Unit is an enhanced processing unit in the PM800 series that provides high-speed data processing, powerful control capabilities, and seamless integration with a wide range of input/output modules, devices, and communication modules to ensure system stability, flexibility, and scalability. The controllers are widely used in automation control systems in the chemical, electric power, petroleum, natural gas, metallurgy, paper and other industries.
Data sheet download:
ABB PM802F 3BDH000002R1 Base Unit controller AC 800F.pdf
Key Features
High-performance processing power
The PM802F controller is equipped with powerful processing capabilities to handle large amounts of process data and control tasks in real-time operation. It supports efficient data processing and multi-task management to ensure high performance and stability of the system.
Modular design
PM802F adopts modular design, which can be used with a variety of I/O modules, communication modules, input/output terminals and other devices, which is convenient for system expansion and maintenance.
High-speed communication interfaces
Equipped with multiple high-speed communication interfaces, it supports Ethernet, Modbus, Profibus, CANopen and other industrial standard communication protocols, enabling efficient data exchange with other devices and systems.
Powerful Control Capability
PM802F supports up to thousands of inputs and outputs, which can complete complex process control, data acquisition and analysis, remote monitoring and other tasks, suitable for a variety of application scenarios.
Redundancy
Provides redundancy options and supports hot backup and redundant operation, which enhances the reliability and fault tolerance of the system and is suitable for industrial environments with high availability and security requirements.
Advanced Diagnostics
Built-in self-diagnostics and real-time fault alarms can quickly pinpoint problems and alert maintenance personnel when faults occur, helping to reduce downtime by providing a timely response.
Flexible Configuration Options
The controller supports flexible configuration options, users can choose the appropriate input and output modules, communication modules and processing units for configuration according to different application requirements, to meet the needs of different scale systems.
Technical Parameters
Model No.: PM802F 3BDH000002R1
Product Type: Base Unit Controller
Input Voltage: 24V DC
Processor Type: High-performance processor, support multi-tasking and parallel processing
Memory: High-capacity memory, supporting multi-point data storage and high-speed computing
Operating temperature range: -10°C to +60°C
Interfaces:
Supports Ethernet and Modbus TCP/IP protocols.
Support Profibus DP, CANopen, EtherCAT and other industrial communication protocols.
Redundancy: Supports hot standby and redundant control
Size: Standard rack mount for 19’ racks.
Protection: IP20 (suitable for industrial environments)
Mounting: DIN rail or standard rack mounting
Diagnostic Function: Supports fault alarm, event logging, historical data storage and analysis.
