The ABB S-113N 3BHB018008R0001 is a high voltage inverter phase module frame. It is part of the ACS2000 series of high
voltage inverters and is used in conjunction with other modules such as the S-076N 3BHB009884R0021 IGCT frame to create
a complete high voltage inverter system.
The S-113N 3BHB018008R0001 High Voltage Inverter Phase Module is designed to control the speed and operation of motors
for energy saving and productivity. It is primarily used in the power and industrial sectors.
The mechanical structure of the phase module includes a closed box and its internal structure. The closed box body includes a frame, a snap-in
back panel, and a front panel. The internal structure includes an IEGT unit, a diode unit, an upper water splitter, a lower water splitter, and an
insulating spacer.The IEGT unit and the diode unit are provided on an insulating plate to form a double-layer structure in the space.
A shunt is provided below the upper and lower manifolds, and the frame on the shunt is provided with a water-cooled quick-connect.
The output bus, driver unit, and grip handle are set on the front panel.
S-113N 3BHB018008R0001 High Voltage Inverter Phase Module is used in various industries such as power and industry. It is used to control the speed and
operation of motors to achieve energy saving and improve productivity.
