ABB PP887S 3BSE092987R1 Touch Screen 15.4"
Touchscreen panels with brilliant TFT/LED display colors and multi-protocol connectivity. The rugged range of Panel 800 comprises of PP886R, PP887H and PP887S that are easy-to use HMI with comprehensive and integrated templates and libraries for every conceivable process you need. All rugged panels are equipped with high-resolution graphics in TFT/LED display. Most models offer wide screen, high resolution display for increased efficiency and excellent operator interaction.
General info
Article number 3BSE092987R1
Category Rugged
Display type Touch
Display size 15.4"
Brightness 1000 cd/m²
Display resolution, ratio 1280 x 800 pixels
Processor ARM9 (1 GHz)
Main memory 2 GB
External storage media 1 × SD card slot (or SDHC with latest image loaded)
Dimension WxHxD (mm) 410 x 286 x 65 mm
Power supply 24 V DC (18 to 32 VDC)
Operating temperature -30 °C to +70 °C
Features and benefits
Easy to use
A fully deployable HMI with comprehensive and integrated templates and libraries for every conceivable process. The Panel Builder tool, with familiar Microsoft® Windows® environment along with multiple language support results in quick, easy and efficient engineering.
State-of-the-arts graphics
Vector-based, high-resolution graphics in TFL/LED display, with icon-based interface, navigation and control.
Robust and reliable
Panel 800 is constructed in a strong yet lightweight diecast, powder-coated aluminum housing. Front casing withstands wet, dusty and demanding environments. Operating temperatures ranging between -30° C to + 70° C with maximum 95% humidity.
Truly open platform
Built on open architecture and technologies that accompany the .NET framework, these panels are capable of multi-brand controller connectivity. A multitude of connection options are available for local communication, expansion, remote access and more.
IP66 Sealed panel
PP887S is a fully sealed version with M12 connectors with IP66 ingress protection rating and ATEX/IECEx Zone 2 and Zone 22 (IP65) certification . The sealed touch panel has the same tolerance for harsh environments, but can be mounted outdoors on a pole, outside of a cabinet.
