ABB AI835A 3BSE051306R1 Analog Input module I/O Systems-S800 I/O. The AI835/AI835A provides 8 differential input channels for Thermocouple/mV measurements. Measurement ranges configurable per channel are: -30 mV to +75 mV linear, or TC Types B, C, E, J, K, N, R, S and T, for AI835A also D, L and U. One of the channels (Channel 8) may be configured for “Cold Junction” (ambient) temperature measurements, thus serving as CJ-channel for Ch. 1...7. The junction temperature may be measured locally on the MTUs screw terminals, or on a connection unit distant form the device. Alternatively, a fix junction temperature for the module may be set by the user (as parameter) or for AI835A also from the application. Channel 8 may be used in the same manner as Ch. 1...7 when no CJ-temperature measurement is needed.
Features and benefits
8 differential input channels for thermocouple/mV.Channel 8 can be designated as the CJ-channel (4-wire Pt100 RTD) Variety of thermocouples with the following characteristics: B, C, E, J, K, N, R, S and T for AI835A also D, L and U 15 Bit resolution (A/D) Inputs are monitored for wire-break open-circuit.
ABB AI835A 3BSE051306R1 Analog Input module I/O Systems - S800 I/O For more products, please click⇒ products
