triconex 9771-210 Input Terminal Board
PRODUCT DETAIL
Product Description:9771-210
Brand：TRICONEX
Description：Input Terminal Board
Termination panel 9771–210 is compatible with 0 to 5 VDC, 0 to 10 VDC, and -5 to +5 VDCanalog input modules. It has 16 power output terminals (+) and 16 current input terminals (–).
Each positive terminal is current-limited with a 180 Ohm series resistor. Each input has aprecision 250 Ohm resistor for 0–5 VDC current-to-voltage conversion
The panel supports redundant 24 VDC power sources with diode ORing.
When using 32-point modules, you must use two term panels for each analog input module.
Triconex is a company that produces safety instrumented systems (SIS) for critical control applications in industries such as oil and gas, petrochemical, and power generation. Their products include programmable logic controllers (PLCs), safety PLCs, and emergency shutdown systems. The Triconex SIS is designed to prevent accidents by automatically shutting down a process when certain conditions are met.
Modules Compatible with 9771–210:3700 0–5 VDC, non-commoned, differential, DC-coupled, TMR;3700A 0–5 VDC, non-commoned, differential, DC-coupled, TMR, +6% input over-range measurement;3703E 0–5 VDC or 0–10 VDC (Use TriStation to configure for 0–5 VDC), non-commoned, differential, isolated, TMR;3721 0 to 5 VDC or –5 to +5 VDC (Use TriStation to configure input range),differential, DC-coupled, TM
