3703E Triconex TMR Tricon Isolated Analogue Input Module

Part number: 3703E

Manufacturer:Triconex

The Triconex 3703E module has 16 input channels that are isolated from each other and ground. It is designed to convert analog signals from field devices such as temperature sensors, pressure sensors, and flow meters into digital signals that can be processed by a Triconex controller. Each input channel can accept a voltage signal between 0-5V or 0-10V1 with a resolution of 12 bits. The input update rate is 50 ms, which means that the module can read the input signals from all 16 channels every 50 ms.

To use the Triconex 3703E module in a Triconex system, you need to install it in a Triconex chassis and configure it using the Triconex programming software. Here are the steps to configure the module:

Install the Triconex 3703E module in an available slot in the Triconex chassis.

Connect the input signals from the field devices to the appropriate input channels on the module.

Use the Triconex programming software to configure the module. This involves setting the input range, scaling factors, alarm limits, and other parameters for each channel.

Download the configuration to the Triconex controller and test the module to ensure that it is working correctly.
