S-093H 3BHB030478R0309 PHASE MODULE ACS6000.The ABB S-093H part number 3BHB030478R0309 is a specialized phase module designed for industrial power distribution and control applications.
General Specification:
ABB Type Designation:S-093H
Catalog Description:PHASE MODULE
Catalog Description:PHASE MODULE(S-093H) FOR 9 MVA
Country of Origin:Poland (PL)
Product Net Weight:220 kg
S-093H 3BHB030478R0309 Functions and Features:
Phase Control and Power Management
Three-phase Balance Regulation: Precisely control the phase balance of three-phase voltage/current to ensure the efficient and stable operation of motor drive systems (such as variable frequency drives) and reduce harmonic interference.
IGBT Drive and Protection: Integrate a high-voltage Insulated Gate Bipolar Transistor (IGBT) drive circuit, support Pulse Width Modulation (PWM) technology to achieve efficient power conversion. At the same time, it has built-in protection functions against short circuits, overheating, overvoltage/overcurrent.
Modular Redundancy Design
Support parallel redundancy with other phase modules. When a single module fails, it will automatically switch to the standby module to ensure the continuous operation of the system (suitable for high-availability scenarios such as power plants and petrochemical plants).
Thermal Management and Reliability
Heat Dissipation Design: Equipped with an aluminum heat sink or a forced air cooling interface to ensure stable operation in high-temperature environments (operating temperature range: -25°C to +55°C).
Vibration Resistance and EMC: Comply with industrial-grade vibration resistance standards (IEC 60068-2-6) and electromagnetic compatibility standards (EN 61800-3), and are suitable for harsh industrial environments.
Application Scenarios
High-voltage Variable Frequency Drive Systems: Used in ABB ACS 1000, ACS 2000, ACS 6000 and other series of high-voltage variable frequency drives to control large motors (such as mine hoists, steel mill rolling mills, marine propulsion motors).
Industrial Process Control: Stirring control of chemical reaction kettles, driving of rotary kilns in cement plants, and tension adjustment of paper production lines.
Energy Infrastructure: Pitch control systems of wind turbines, turbine speed regulation in hydropower stations, and control of auxiliary equipment of gas turbines.
