The PFCL201CE-50KN indenter is made from a single piece of stainless steel and is very robust with a high coefficient of elasticity. It is able to be mounted under the bearing housing to measure the vertical component force, which can be measured in both directions.The load cell is machined directly into the steel sheet and is positioned so that it is sensitive to forces in the direction of measurement and insensitive to other directions. The load cell is mounted to the base with four screws and the bearing box is mounted to the top of the load cell with four screws. Each load cell is calibrated and temperature compensated. The load cells PFCL 201C/201CE/201CD are available in four measuring ranges and all variants have the same external dimensions. The pressure measuring element PFCL 201C is equipped with connectors for pluggable connection cables. The load cell PFCL 201CE has a fiWed connection cable with protective hose. The load cell PFCL 201CD is equipped with an acid-resistant cable sealing sleeve and a PTFE-insulated connection cable.
To learn more about this product click on the file below or download the file:
ABB PFCL201 Vertical Measuring Pillow Indenter.pdf
PFCL201CE 50kN 3BSE027062R50 Performance Parameters
Precision:0.2%
Power consumption: ≤3VA
Frequency withstand voltage: AC2 0KV/min.1mA (input ~ output / power supply between)
Insulation resistance: ≥20MQ (DC500V)
Impulse voltage: 5KV (peak 1.2/50μs)
Response time: <350ms
Input range: AC0~10A, AC0~500V (optional), 50/60Hz
Absorbed power: < 0.5VA/450V, < 0.2VA/100V, < 0.1VA/5A
Load resistance: current output ≤ 550Q; voltage output ≥ 2KQ
Operating Environment:Temperature: -10~50°C Humidity: 20~95%. No condensation
Storage environment: Temperature: -40~70°C, Humidity: 20~95%, no condensation.
Mounting: 35mm DIN rail mounted or M4 screw fixed
Load cell PFCL 201CE 50KN with insulated cable connection
Product dimensions and weights are shown:
Dimensions:(45CM×12CM×11.5CM)
Weights:(50kg)
Country of origin: (Sweden)
