ABB 5SHY35L4520 5SXE10-0181 AC10272001R0101 Asymmetric Integrated GateCommutated Thyristor

Part number: 5SHY35L4520

Part No:5SXE10-0181

Manufacturer:ABB

Product Description:IGBT module

The 5SHY35L4520 is a non-symmetrica lGCT module that can handle a maximum voltage of 4500V and a maximum current of 4000A. It is designed for use in high-power applications such as in the power grid and industrial drives. The device contains an integrated gate commutated thyristor (IGCT) that provides high-speed switching and voltage blocking ability. The IGCT is a combination of a gate unit and a commutated thyristor, which provides better performance than a traditional thyristor. The device is known for its high reliability, low power loss, and low cost.

A Gate Commutated Thyristor (IGCT) is a type of thyristor that is used in high voltage and high power applications. It is an improved version of the traditional thyristor with additional features like high-speed switching and voltage blocking ability. A GCT is a four-layer semiconductor device that has a gate, anode, cathode, and a p-base. When a positive gate signal is applied, the device turns on and starts conducting the current. When the gate signal is removed, the device turns off and stops conducting the current.
