In the energy sector, dispatch is the operational planning of power plants. It is the process in which transmission system operators decide which power plants and generation plants are used to meet current electricity demand. This involves optimising costs and efficiency while ensuring security of supply.
What Is a Power System Dispatcher?
A power system dispatcher directs the distribution of electricity between providers and consumers, both residential and commercial. As a power system dispatcher, you monitor generator systems to ensure optimal efficiency and determine how much power is needed for each day. Discretion is particularly vital during extreme weather conditions, such as heat waves or snowstorms. Other job duties include responding to calls of shortages or repairs and coordinating crews out to the location to fix the problem.
What Are the Education Requirements to Become a Power System Dispatcher?
Power system dispatchers need to have a high school diploma or equivalent. They also need to complete an apprenticeship in electrical dispatching or electric utility operations. These apprenticeships typically last two to three years. To become a power system dispatcher, you must know GIS applications and electric utility systems such as SCADA, an understanding of how to build and maintain a database, and know how to read electrical circuit drawings.
Where Does a Power System Dispatcher Work?
A power system dispatcher works in an office setting, often in a power plant. They monitor equipment using a computer, coordinating with crews to complete needed repairs, and communicating with engineers and planners to provide information about clearances, orders, and distribution changes. Some positions may require you to work out in the field to monitor repairs and new installations. You may also travel to other offices to discuss power supplies and other issues.
What Is a Typical Work Day for a Power System Dispatcher?
During a typical workday for power system dispatchers, they regulate, track, and monitor energy distribution. To ensure all clients are receiving the correct amount of electricity at all times without disruption, you operate various supply equipment, monitor transmitters, and regulate the power flow as needed. Rotating shifts are common and being at a workstation may be required for your whole shift. You communicate with power plant operators, traders, and local companies frequently, and take note of any weather changes that may affect service. Power system dispatchers may need to be on call for emergencies, and sometimes work evenings, weekends, and holidays.
The following brands of Power system dispatching products are shared for your reference and selection:
1.Siemens S7-400 series PLC module: It is suitable for station-level control and regional control of medium and large substations and power grid dispatching. With powerful communication capability, it can interact with other devices via Profibus, Profinet and other communication protocols to achieve remote monitoring of power grid equipment and rapid transmission of control commands. Its powerful CPU module can handle complex control logic and a large number of data calculations, which meets the high requirements for data processing and real-time control in power grid dispatching.
Related Product Category:
Power supply module: such as 6ES7 407-0DA01-0AA0 (4A), 6ES7 407-0KA01-0AA0 (10A), etc., to provide stable power supply for PLC system.
CPU: Covering a wide range of models from entry-level to high-performance, such as CPU412, CPU414, CPU416, CPU417, etc. Different models have different memory and processing speeds to adapt to different scales and complexity of the control task.
Memory card: 6ES7 955-2AL00-0AA0 (2X2M bytes RAM), 6ES7 952-0AF00-0AA0 (64K bytes RAM) and other specifications, used to expand the storage capacity of the CPU.
Switching input templates: 6ES7 421-7BH01-0AB0 (16-point, 24VDC interrupt), 6ES7 421-1BL01-0AA0 (32-point, 24VDC), etc. are used to collect digital input signals.
Switching output templates: like 6ES7 422-1BH11-0AA0 (16-point, 24VDC, 2A), 6ES7 422-1BL00-0AA0 (32-point output, 24VDC, 0.5A), etc., used to output digital control signals.
Analogue I/O modules: such as 6ES7 431-0HH00-0AB0 (16 inputs), 6ES7 432-1HF00-0AB0 (8 outputs), etc., can process analogue signals.
Processor Module: 6ES7488-3AA00-0AB0
2.Yokogawa CENTUM VP Series DCS Modules: Widely used in the main grid control of large-scale power grid dispatch centres and in regional distribution network dispatch. The I/O modules of this series have high-precision data acquisition and processing capabilities, and are capable of accurately acquiring a variety of analogue and switching signals in the power grid and transmitting the data reliably. The control module is equipped with rich control algorithms and logic functions to achieve precise control and optimal scheduling of the power grid, while the redundant design of the system ensures high reliability and stability of power grid scheduling.
Related Product Category:
CP461-50 S1: High-performance processor module with high-performance CPU, large memory capacity, dual redundancy, and various communication interfaces.
Input and output modules
Analogue input module: AAI141 (4-20mA, 16 channels, non-isolated), AAI143 (4-20mA, 16 channels, isolated), AAV141 (1-5V, 16 channels, non-isolated), AAV144 (-10V ~ +10V, 16 channels, isolated), AAT141 (TC/mV input module, 16 channels, isolated), and so on.
Analogue output modules: AAV542 (-10V ~ +10V, 16 channels, non-isolated), AAI543 (4 ~ 20mA, 16 channels, isolated), AAV544 (-10V ~ +10V, 16 channels, isolated) and so on.
Digital input module: ADV151 (32 channels, DC24V, isolated), ADV141 (16 channels, 100V ~ 120V AC, isolated), ADV161 (64 channels, DC24V, isolated) and so on.
Digital output modules: ADV551 (32-channel, DC24V, isolated), ADV561 (64-channel, DC24V, isolated), ADR541 (16-channel, 24-110VDC/100-240V AC, isolated), etc...
Power Module
PW441: 100-120V AC input power supply module, with suffix codes such as - 5, -E, 0, 1, etc., which stand for standard without Ex protection, standard with Ex, basic, G3 option with ISA standard, etc., respectively.
PW442: 220-240V AC input power supply module, suffix code meaning the same as PW441.
PW444: 24V DC input power supply module, suffix code meaning the same as PW441.
